Chinese Factory Supply Structural Galvanized Purlins C/Z/U Beam Steel Channel Building

Quantity:
Availability:





Inquire Add to Basket

Product Description

Standard	GB, ASTM, AISI	Place of Origin	JiangSu, China
Material	Carbon Steel, Stainless Steel	Brand Name	BINMU
Shape	C Channel, c channel u channel	Application	Building Material, Construction
Tolerance	±3%	Processing Service	Bending, Welding, Punching, Decoiling, Cutting
Invoicing	By Theoretical Weight	Delivery Time	7~21 days
Surface treatment	Power Coated, GI, HDG	Length	3m/6m/customized
Payment terms	30%T/T Advance + 70% Balance	Thickness	1.5mm-3.75mm
Loading port	Shanghai Port	Bussiness type	Manufacturer

These sections are manufactured from S275JR grade steel and have excellent machinability and weldability. Our stocks are available in mill finish, red oxide, or Zinc finishes to offer a range of corrosion resistance properties to suit your project. To increase corrosion resistance mild steel is normally painted or galvanized after fabrication.
Mild steel channel is widely used in civil engineering and construction to support floor joists and to weight bear above window and door gaps where the structural load does not require an I beam.
If you are uncertain whether your project requires mild steel C channels or an I beam, we recommend you consult a structural engineer or other qualified professional.
Mild steel channel is supplied in lengths up to 6 meters long and can be easily cut, drilled, and machined. It is particularly suited to all methods of welding. Mild Steel Channel is produced to grade EN 10025-2 S275JR one of the most widely used steel specifications for general construction.

Nominal Size (mm)	Depth of Section (mm)	Flange Width (mm)	Flange Thickness (mm)	Web Depth (mm)	Web Thickness (mm)	Weight (kg/m)	Metres/ Tonne (m/t)	9m	10.5m	12m	13.5m	15m	16.5m	18m
100 x 50	100	50	6.70	87	4.20	8.33	120	✓		✓
125 x 65	125	65	7.50	110	4.70	11.90	84	✓		✓
150 x 75	150	75	9.50	131	6.00	17.70	57	✓	✓	✓	✓	✓	✓	✓
180 x 75	180	75	11.00	158	6.00	20.90	48	✓	✓	✓	✓	✓	✓	✓
200 x 75	200	75	12.00	176	6.00	22.90	44	✓	✓	✓	✓	✓	✓	✓
230 x 75	230	75	12.00	206	6.50	25.10	40	✓	✓	✓	✓	✓	✓	✓
250 x 90	250	90	15.00	220	8.00	35.50	28	✓	✓	✓	✓	✓	✓	✓
300 x 90	300	90	16.00	268	8.00	40.10	25	✓	✓	✓	✓	✓	✓	✓
380 x 100	380	100	17.50	345	10.00	55.20	18	✓	✓	✓	✓	✓	✓	✓
50 x 25	50	25				3.83	261	✓		✓

Standard Equivalent
China GB/T, YB	America ASTM	Japan JIS	Germany DIN EN	England BS EN	France NF EN	ISO	Korea KS	India IS
Q195	Grade B	SS330 SPHC	S185(1.0035)			E185 Fe(310)		D
Q215	Grade C CS Type B						SS330 (SS34)	Fe-330
Q235-A	Grade D	SS400	S235JR (1.0038)			E235 A E235 B E235 C E235 D	SS400 (SS41)
Q235-B			S235J0(1.0114)					Fe-410
Q235-C			S235J2(1.0117)
Q235-D			S235JR(1.0038)
Q275	SS Grade 40 (275 )	SS490	S275JR(1.0044) S275J0(1.0143) S275J2(1.0145)			E275 (Fe430)	SS490	Fe-490
Q345-A	Grade 50 (345)	SPFC590	E355(1.0060)			E355
Q345-B			S355JR(1.0045)
Q345-C			S355J0(1.0553)
Q345-D			S355J2(1.0577)
Q345-E			S355NL(1.0546)

Stainless Steel Back to Back U Strut Channel Factory

1.Can you provide some samples for me?

Yes, we can provide free samples to you, but the freight need you to bear. Please send sample list by email.

2. Why should I choose you?

(1) Contact us with your detailed inquiry, you will be replied within 24 hours.

(2)You are promised to obtain the best quality, price and service.

(3) We'd like to provide samples for your confirm.

(4) Wide excellent experiences with after-sale service.

(5)Every process will be checked by responsible QC which insures every product's quality.

3. How does your company do regarding quality control?

Each year we have quality supervision department inspection, and issue inspection reports, each batch of goods will be strictly controlled, the company's internal will have quality regulation, to ensure that every batch of products qualified and best quality.

4. Can provide a catalogue for me?
The electronic version can be submitted by e-mail or the hard copies of catalogs are free but freight should be collected.

5. Can you guaratee your products?

Yes, we guarantee your 100% satisfaction on all our products. Please feel free to feedback us immediately if you are not satisfied with our quality or service. If the product does not meet the contract requirements, we will send you a free replacement or give you compensation in the next order.

C Type Channel Steel Steel from Chinese Manufacturer Structural Steel C Channel Channel Beam Steel Purlins C Section Structural Steel stainless steel channels u-type channel bar hot rolled ss316 ss316l u-type channel bar

PRODUCT INQUIRY

RELATED PRODUCTS

Hot Rolled Cold Formed Steel Profile C U Z Shape Steel Channel Profile Price

Q235 Galvanized Angle Structure Bar/Beam

2x2 Angle Iron Equal Angle Steel Price Per Kg Ms Steel Angle Bar

Hot Rolled Origin In China Steel Other Products Stainless Bar Flat Bar Steel

Steel Galvanized Flat Bars Q235 S235 S275 Iron Mild Steel Flat Bars

ASTM A36 Hot Rolled Carbon Steel Sheet / Steel Plate/MS Sheet

Factory Supply ASTM A36/ASTM A283 Grade C Mild Hot Rolled Carbon Steel Plate for Building Material

Best Price Q235 Q345 Mild Carbon Steel Plates Carbon Steel Plate For Industrial

China Steel Steel Rebars Hot Rolled Deformed Steel Rebar Supplier

Brand New Stainless Steel Channels Iso C Channel With High Quality

Q235B A36 Black H/I Beams Iron

Hot/Cold Rolled Steel Plate/Sheet for Building

1/6 Hot Dipped Galvanized Round Steel Pipe/gi Pre Tube

Q235b 200x200 Rectangular And Square Pipe/Tube

Round Stainless Steel Pipe

Anti Seismic Deformed Steel Bar Hrb400 Steel Rebar Structural Steel Rebar

Cheap Wholesale PPGI Line White Sheet Coil Sheet Iso GI Steel Prepainted Galvanized Steel Products Galvanized Coated

Galvanized Heavy Duty Slip Resistant Industrial Non-Slip Steel Grating

Cheap Prefabricated Steel Structure Warehouse

Galvanized U Channel Purlin

Type	Height	Width	Thickness	Theoretical weight
5#	50	37	4.5	5.438
6.3#	63	40	4.8	6.634
8#	80	43	5.0	8.045
10#	100	48	5.3	10.007
12#	120	53	5.5	12.059
12.6	126	53	5.5	12.319
14#a	140	58	6.0	14.535
14#b	140	60	8	16.733
16#a	160	63	6.5	17.24
16#b	160	65	8.5	19.752
18#a	180	68	7	20.174
18#b	180	70	9	23
20#a	200	73	7	22.637
20#b	200	75	9	25.777
22#a	220	77	7	24.999
22#b	220	79	9	28.453
25#a	250	78	7	27.41
25#b	250	80	9	31.335
25#c	250	82	11	35.26
28#a	280	82	7.5	31.427
28#b	280	84	9.5	35.832
28#c	280	86	11	40.219
30#a	300	85	7.5	34.463
30#b	300	87	9.5	39.173
30#c	300	89	11.5	43.883
32#a	320	88	8	38.083
32#b	320	90	10	43.107
32#c	320	92	12	48.131
36#a	360	96	9	47.814
36#b	360	98	11	53.466
36#c	360	100	13	59.118
40#a	400	100	10	58.928
40#b	400	102	12.5	65.208
40#c	400	104	14.5	71.488

Type	Height	Width	Thickness	Theoretical weight
5#	50	37	4.5	5.438
6.3#	63	40	4.8	6.634
8#	80	43	5.0	8.045
10#	100	48	5.3	10.007
12#	120	53	5.5	12.059
12.6	126	53	5.5	12.319
14#a	140	58	6.0	14.535
14#b	140	60	8	16.733
16#a	160	63	6.5	17.24
16#b	160	65	8.5	19.752
18#a	180	68	7	20.174
18#b	180	70	9	23
20#a	200	73	7	22.637
20#b	200	75	9	25.777
22#a	220	77	7	24.999
22#b	220	79	9	28.453
25#a	250	78	7	27.41
25#b	250	80	9	31.335
25#c	250	82	11	35.26
28#a	280	82	7.5	31.427
28#b	280	84	9.5	35.832
28#c	280	86	11	40.219
30#a	300	85	7.5	34.463
30#b	300	87	9.5	39.173
30#c	300	89	11.5	43.883
32#a	320	88	8	38.083
32#b	320	90	10	43.107
32#c	320	92	12	48.131
36#a	360	96	9	47.814
36#b	360	98	11	53.466
36#c	360	100	13	59.118
40#a	400	100	10	58.928
40#b	400	102	12.5	65.208
40#c	400	104	14.5	71.488

Packaging details	1.Big order: in bulk
	2.Small order: packed by steel strips
	3.woven cloth with 7 slats
	4.according to the requirements of customers
	5. 20ft container can load 25 tons, 40ft container can load 26 tons.
Delivery	3-15 working days after received the deposit or L/C.
Payment terms	30% TT deposit, 70% balance before shipment.

Packaging details	1.Big order: in bulk
	2.Small order: packed by steel strips
	3.woven cloth with 7 slats
	4.according to the requirements of customers
	5. 20ft container can load 25 tons, 40ft container can load 26 tons.
Delivery	3-15 working days after received the deposit or L/C.
Payment terms	30% TT deposit, 70% balance before shipment.
